HST Passiv

HST Passiv lifted and sliding doors with 85 mm sash and 197 mm frame have been created for unlimited freedom of space creation.

The HST doors meet the three most-awaited criteria by customers:

TIGHTNESS – a system based on a profile of a leading Aluplast brand is one of the most impermeable solutions in its class. During tightness tests, he achieved an excellent result – a grade 8a (450 Pa). Thanks to this, even during the most extreme weather phenomena, HST Passiv will fulfill its task.

THERMAL INSULATION – with the use of deep construction of the sash, we can use very “warm” glass packages (Ug 0.5 or 0.6 W / m2K), thanks to which we achieve excellent thermal insulation. Depending on your needs, to achieve the lowest possible value of the UW dedicated to passive and zero-energy houses, we suggest selecting a solution using the HST Passiv system.

LARGE DIMENSIONS – HST COMFORT and HST Passiv also meet the next demand of the construction market, allowing for the construction of windows in this class with maximum dimensions for a width of 6000 mm and a height of 2500mm. Thanks to the modern machine park, we can offer you the performance of these windows in any available colour, regardless of the window system, you will decide to use our offer.

HST Lift & Slide doors can come in at least several different versions and arrangements of sashes and non-opening parts.

Technical Documentation

Colors

SAMPLE DOOR SCHEMES:

Send an Inquiry

Pakiet Titan

Podnieś okno do wersji PREMIUM wybierając pakiet TITAN, o którym więcej dowiesz się poniżej.

Okucie SIEGENIA TITAN AF

Posiadające obrotowe, samonastawne rolki KoPiBo (umożliwiającymi łatwą i komfortową obsługę).

Rolki KoPiBo

Zaczep Antywyważeniowy

Podnośnik skrzydła wraz z blokada błędnego położenia klamki

Mikrowentylacja

Wypełnienie dolnego rowka okuciwego

Klamka Aluminowa Premium

Rolki KoPiBo

Zaczep Antywyważeniowy

Podnośnik skrzydła wraz z blokada błędnego położenia klamki

Mikrowentylacja

Wypełnienie dolnego rowka okuciwego

Klamka Aluminowa Premium

HANDLE-CONTROLLED OPENING BRAKE

  • individual adjustment of opening width: casement is blocked at any desired orientation
  • keeps the casement in the open position even in strong wind
  • easy to retrofit

ROTATING MUSHROOM SWIVEL

  • locking element in the form of a rotating mushroom, which enables smooth and trouble-free opening, tilting, and closing of windows
  • adapts automatically to changing conditions, for example to the ambient temperature
  • enables-smooth adjustment of pressure

ANTI-BURGLARY CATCH

  • a new generation of latches provides high security and low friction levels

CASEMENT LIFT

  • prevents sagging of casements, ensures smooth closing, prevents mishandling

BALCONY SNAPPER CATCH

  • together with a handle, it allows shuƫng the window from the outside, protects against loosing heat from a room, deactivated in the tilt position

STANDARD HINGE

SPS MICRO-VENTILATION

  • constant supply of the necessary volume of fresh air without drafts
  • minimized risk of fungus and a healthy climate in the room

WINTER-SUMMER AIR LATCH

  • reduces heat loss and saves energy
  • in the summer, a window is tilted as usual; in the winter the tilt is limited to approx. 40 mm
  • integrated protection against closing shut

GRADUAL TILT

  • enables adjusting the intensity of ventilation; windows can be set in 5 different positions (tilt range from 4 to 33 mm)

HIDDEN HINGE

  • gives windows a subtle look
  • excellent durability and low wear of elements
  • continuous sealing guarantees excellent thermal and acoustic insulation
  • numerous adjustment possibilities allow maintaining smooth operation of casements for a long time
