AMI Air Inlet

Pressure air inlet with AMI sound-proofing with the acoustic

possibility of setting the diaphragm in the minimum flow position.

The air flow through the air inlet depends on the differential pressure outside and inside the room. It is possible to set the diaphragm to the minimum flow position. The air inlet is equipped with a lock that will not allow you to increase the air flow at a specified performance. The air inlet can be used in PVC, wooden and aluminium windows.

Typepressure, self-regulating, acoustic air inlet
Principle of operationthe amount of air flow depends on the pressure difference inside and outside the room
Air flow at a pressure difference of 10 Pa5-22 m³/h
Acoustic muffling/attenuation37 dB
Dimension390 x 39 x 43 mm (W x H x D)
Colourwhite, chestnut, oak, can be painted in any colour from the palette RAL
Technical approvalITB AT-15-8460/2010
